Burn Through 70um 100GSM Anti Laser Embroidery Film
Contact Person : Kim
Phone Number : 13106379170
WhatsApp : +8615639785569
| Minimum Order Quantity : | 500kgs | Price : | USD5-8/kg |
|---|---|---|---|
| Packaging Details : | Rolls | Delivery Time : | 5-8 days |
| Payment Terms : | L/C, D/P, T/T, Western Union, MoneyGram | Supply Ability : | 1000kgs/day |
| Place of Origin: | China | Brand Name: | SNYC |
|---|---|---|---|
| Certification: | SGS,ISO9001 | Model Number: | Hot water soluble film |
|
Detail Information |
|||
| Material: | 100% PVA (Polyvinyl Alcohol) | Thickness: | 45um,50um,60um70um |
|---|---|---|---|
| Width: | 160CM | Dissolving Temperature: | 90-100c |
| Color: | Transparent | Suface: | Embossed |
| Packing: | 200m,500m In Roll | MOQ: | 50rolls |
| Loading Port: | Shanghai | ||
| Highlight: | 35um Anti Laser Embroidery Film,100degree Anti Laser Embroidery Film,100degree sticky backing for embroidery |
||
Product Description
Water-soluble anti-laser embroidery burn-through membrane/film
Product description:
1. The weight of the water-soluble paper in the reference list of the anti-laser burn-through ability is adjusted according to the laser intensity, fabric thickness and hardness of the customer’s product;
2. A 16-20 g water-soluble paper should be place under the laser membrane/film to support the membrane/film. According to the air temperature, humidity, and tension of the embroidery table in the customer’s workshop environment, it can also be used without placing the water-soluble paper;
3. The water-soluble anti-later embroidery membrane/film has excellent resistance to laser burn-through, which is twice as strong as water-soluble paper. During laser cutting, the fabric has less burnout, the speed is faster, the edges are neater, and the yield is higher.
Specification:
| Model | Laser burn-through resistance (GSM) | Dissolving temperature (℃) | Width(MM) |
| G-XKJ-1 | 90-100G | 90-100 | 1600-1800 |
| G-XKJ-2 | 100-110G | 90-100 | 1600-1800 |
| G-XKJ-3 | 110-120G | 90-100 | 1600-1800 |
| G-XKJ-4 | 120-130G | 90-100 | 1600-1800 |
Water-soluble anti-laser embroidery burn-through membrane/film
G-XKJ(Transparent,High temperature)Water-soluble anti-laser embroidery burn-through membrane/film specification
Thickness and width is customized according to demand.
G-XKJ(Transparent,Low temperature)Water-soluble anti-laser embroidery burn-through membrane/film specification
(Water temperature 25-30℃)
| Model | Thickness(UM) | Width(MM) |
| D-XKJ-45T | 45 | 1600 |
| D-XKJ-50T | 50 | 1600 |
| D-XKJ-60T | 60 | 1600 |
| D-XKJ-70T | 70 | 1600 |
D-XKJ Plain/Embossed surface (Cold water soluble) embroidery film
(Water temperature 25-30℃)
| Model | Thickness(UM) | Width(MM) |
| D-XKJ-25 | 25 | 1600 |
| D-XKJ-35 | 35 | 1600 |
| D-XKJ-45 | 45 | 1600 |
| D-XKJ-50 | 50 | 1600 |
| D-XKJ-60 | 60 | 1600 |
| D-XKJ-70 | 70 | 1600 |
